Swift Bolero User Manual

Electrical Systems
3.5 FUSE / MCB TABLE
WARNING: When replacing fuses always replace a fuse with the correct value. NEVER replace with a higher value / rating as this
could damage the wiring harness. If a replacement fuse ‘blows’ do not keep replacing the fuse as you could damage the wiring
harness. Please contact your dealer.
41
Fuse Rating Fuse Colour Wire Colour Description
1
2
3
4
5
6
7
8
Battery
15 Amps
15 Amps
10 Amps
10 Amps
5 Amps
5 Amps
10 Amps
20 Amps
20 Amps
Blue
Blue
Red
Red
Tan
Tan
Red
Yellow
Yellow
Slate
Pink
Yellow / White
Black / Tracer
Yellow / Green
Slate / Red
Green/Tracer/Purple
*
Brown / Blue
Front Lights
Rear Lights
12v Sockets
Fans
Heater / Hob / Other Ignitions (if fitted)
Aux / Awning Light
Water Pumps / Toilet
Charger (internally connected)
Fuse remotely located near battery
MCB Rating Wire Colour
White
White (Yellow for heater)
Black (Blue for water heater)
Description
1
2
3
10 Amps
10 Amps
6 Amps
240v sockets
Extra 240v Sockets / Heater
Fridge / Water Heater / 12v Charger (internally connected)
