Electrical Systems
43
Display Description Options / Notes
EC200 v1.1H
12:00 23.9°C
Leisure Battery
12.5v (Good)
Vehicle Battery
13.3v (Good)
Fresh Water
25% Full
Waste Water
0% Full
External Temp
26.5°C
Battery Current
5.4 Amps
Main Control Panel display showing modelnumber
(EC200), software version number (v1.1), specification
(H), current time (12:00) and internal temperature
(23.9°C) in centigrade
Voltage reading and battery condition description for
the on-board leisure battery
Voltage reading and battery condition description for
the vehicle battery
See section 4.4 for details of the Vehicle Battery save
feature
Water level in the fresh water tank
(5 measurement levels)
Water level in the waste water tank
(2 measurement levels)
External temperature (in degrees centigrade) as
measured by the external temperature probe
(only available in H specification systems)
Current (in Amps) being drawn from or charged into the
selected battery
(only available in H specification systems)
The addition of an asterisk (*) in the top left of the
display indicates that the alarm is set
<10.9 = (Poor)
10.9 to 11.8 = (Fair)
11.9 to 14.4 = (Good)
<10.9 = (Poor)
10.9 to 11.8 = (Fair)
11.9 to 14.4 = (Good)
0% <
1
⁄4 Full (Empty)
25% >=
1
⁄4 Full
50% >=
1
⁄2 Full
75% >=
3
⁄
4 Full
100% = Full
0% <
1
⁄2 Full
50% >=
1
⁄2 Full (optional)
100% = Full
Negative figure (-) = current being drawn from the
selected battery
Positive figure = current being used to charge the
selected battery
4.2 MENU FUNCTIONS - Readings section
