88
Equipment Details
C-200 CW only C-200 CWE only
C-200 CW
only
05
04
06
04a 06 16
04b
03
01
02
08 07 09 14 12
13
11
14
10
15
THETFORD CASSETTE
C-200 CW (Manual)
and C-200 CWE (Electric)
FEATURES
1. Removable seat and cover.
2. Rotatable bowl.
3. Valve blade handle: opens and closes
valve blade.
4. Flush-handle activates the flush by lifting
and pushing down the handle.
4a C-200 CWE. Flush button: activates
flush.
4b C-200 CWE. Valve blade buttons: open
and close valve blade electronically.
5. Power-supply for the waste-level
indicator: two batteries, type: Penlite 1,5V
AA alkaline.
6. Waste-level indicator: indicates when
holding tank requires emptying.
7. Rotating pour-out spout: makes emptying
holding tank easy and convenient.
8. Upper carrying handle
9. Automatic holding tank vent: vents the
holding tank when the tank is inserted in
the toilet. This prevents under- or
overpressure in the holding tank.
10. Valve blade opener.
11. Sliding cover: closes automatically when
holding tank is taken out. Guarantees
optimal hygiene.
12. Valve-blade
13. Vent button: vents the holding tank to
avoid splashing while emptying.
14. Hand grip
15. Access door
16. Waterfill door
