SWorkz S12-2 - Page 18

18
23
24
330300
2502401BK(#4)
2502401BK(#4)
2502401BK(#5)
2502401BK(#5)
2502401BK(#5)
2502401BK(#4)
330300
330300
330643
17.6 mm17.6 mm
20.40 mm20.40 mm
18.0 mm18.0 mm
330300
Rear Upper Sus. Arm Turnbuckles
x4
330300
Rear Upper Sus. Arm Turnbuckles
x2
(U.A.L.)(U.A.L.)
(Upper Arm Linkage)(Upper Arm Linkage)
(Steering Linkage)(Steering Linkage)
(S.T.)(S.T.)
330643
Steering Linkage Ball Stud 5mm
x2
