22
31
32
108028
BAG
D
ESC is not includedESC is not included
Receiver is not includedReceiver is not included
104004
M3x3mm Set Screw
x1
200193
220042
220043
220043
104004
106008
106008
108028
M2.6x4mm Flat Head Screw - Hex Socket
x4
106008
M3x12mm Hex Socket OH/TP Screw
x2
PRO TIP:
Use part 220043 Battery Post A and B to change your battery positions.
When Post A is on the left chassis side and Post B on the right side, you
can have 3 different battery positions near the motor. While on the other
hand, when Post A is on the right side of the chassis and Post B on left
side, there can be another 3 battery positions near the ESC plate. There
are a total of 6 different positions to place the shorty battery.
