SWorkz S35-3 - Page 17

17
20
21
BAG
E3
2503260-8
210051
2503260-27
2503260-27
330574
104011
2503264
2503264
2503260
330118A
106002
330774
330774
330118A
330252
330252
Screw and adjust 330118A Knuckle
Pivot Ball Nut so as the pivot ball can
be moved smoothly.
Left
Right
104001
M5x4mm Set Screw
x2
330124
Pin M3.0x16.8mm
x2
116017
116017
330576
106002
M3x10mm Hex Socket OH/TP Screw
x1
116017
Ball Bearing 6x12x4mm
x4
