SWorkz S35-3 - Page 19

19
24
25
13.85mm
103001
103001
2503260-7
330782
330782
330125
2503270-2
2501121C-4
330123A
Rear Upper Sus. Arm Turnbuckles
x2
330782
Rear Hub Carriers Hing Pin with Nut
x2
103001
M3 Nut Lock
x2
2503260-6
330125
330123A
2503260-7
2503260-6
2503260-7
2503260-7
Pro Tip:
The base set up is always by using 2-3mm inserts on
the rear of Hub Carriers Hinge Pins.
The wheel base length should be around 327-328mm.
