SWorkz S35-3 - Page 26

26
38
39
Laps transponder is not
included in the kit.
The switch is not
included in the kit.
Receiver and switch are
not included in the kit.
Servos are not
included in the kit.
106008
M3x12mm Hex Soket OH/TP Screw
x4
106005
M3x15mm Hex Soket OH/TP Screw
x4
106002
103001
106008
106008
106003
106003
2503262-4
2503262-3
2503262-3
106002
M3x10mm Hex Socket OH/TP Screw
x3
103001
M3 Nut Lock
x2
