SWorkz S35-3 - Page 29

29
45
BAG
G
BAG
M1
106020
106002
210033A
2501115B-4
2502040-5
210033A
108006
108006
106002
2501125B
2501125B
2501125B
106002
103001
M3 Nut Lock
x1
108006
M3x8mm FH/ST HEX Screw
x1
108006
M3x8mm FH/ST HEX Screw
x2
106002
M3x10mm Hex Socket OH/TP Screw
x3
When the volume
of fuel tank system
is over 125cc,
using the part
200167 can be
reduced 2cc for
your fuel tank.
SW-330423A S350 PSP System
Aluminum Settring Bellcrank Upper (A 2H )
Assembly Note
If servo saver arms are not included use this:
Position A: Standard steering response location. Use of a
2.5mm longer servo saver arm is required.
If servo saver arms are included use this:
Position A: Standard steering response location. Use of
the included 2.5mm longer servo saver arm is required.
Position B: Quick steering response location. Standard
servo saver arm can be used.
Position A
Position B
106007
M3x12mm Hex Socket
x8
OH/TP Screw(HT)
44
108006
106007
106020
M2.5x5mm Hex Socket OH/TP Screw
x2
