SWorkz S35-4 EVO - Page 28

28
43
BAG
H
BAG
G
106020
106002
210033-D90
2501115
2502040
210033-D90
108006
108006
106002
210033-D90
210033-D90
106002
103001
M3 Nut Lock
x1
108006
M3x8mm FH/ST HEX Screw
x2
106002
M3x10mm Hex Socket OH/TP Screw
x3
When the volume
of fuel tank system
is over 125cc,
using the part
210033-D90 can
be reduced 2cc for
your fuel tank.
210033-D90
42
105012
103001
106007
106020
M2.5x5mm Hex Socket OH/TP Screw
x1
106007
M3x12mm Hex Socket
OH/TP Screw (HT)
x1
105012
M3x10mm Cap Screw
x2
