Linkage
Adjustment
Turn on the transmitter and receiver. Set the throttle servo
trim in neutral. Adjust the idle adjustment screw to make the
carburettor opening no more than 1mm. Adjust the position
of servo horn. Check that it operates smoothly without
making the operation of the other parts difficult.
Make sure the brake does not work in this setting.
Neutral Full Throttle Brake
Idle adjustment screw
※
Adjust the servo horn to fully open the
carburettor. Change the position of
servo horn if the carburettor is not fully
open or opens too much. If your transmitter
has a function to adjust throttle end points,
make an adjustment this way.
※
Adjust the position of servo horn to make
the brakes function. Make sure the brakes
do not work when the servo trim is in
neutral.
※
