SWorkz S35-T2e - Page 12

12
11
10
BAG
E1
106013
104005
M3x4mm Set Screw
x2
106013
M2.5x8mmH ex Socket OH/TPScrew
x
2
104005
106013
104005
108006
M3x8mm FH/ST HEX Screw
x2
108003
108003
M3x10mm FH/ST HEX Screw
x2
108006
338057
340017
108006
Note:
The aluminum front upper arm holder (338057) can offer either
0° or + -1° kick-up for your front upper arm suspension.
You may use the inserts 228001(#13) to get 0° kick-up
or 228001(#12) to get +-1° for your front upper suspension.
228001(#11 #12 #13)
