SWorkz S35-T2e - Body Shell Assembly; Body Shell Preparation and Mounting (Bag M)

32
BAG
M
49
50
Use water/washing
solution to clean
body.
Paint body.
Apply window masks
as shown.
510110M
10mm
6mm
Attention!
The S35-T2e body post positions are different as of the body shell's.
Please check the “RED DOTs” marked on the body shell. Or follow
the manual's instructions for the actual body posts positions.
Use body scissors
to cut along the
body lines.
250049A
