SWorkz ZEUS - Page 11

11
8
9
330831
2503260-24.25
2.0mm
330103
Front/Rear Lower Arm HingPin
x2
Use a 2mm Hex Wrench and
slowly tighten the Hinge Pins.
108008
108008
M3x35mm FH/ST HEX Screw
x2
101020A
3mm Countersunk
x2
Washers (GM)
101020A
2503260-24.25
2501100
2501100
330103
2501114
104004
104004
115008
104004
M3x3mm Set Screw
x2
Pop in the Stabilizer Guide.
After assembly ensure that both
suspension arms move freely.
