SWorkz ZEUS - Parts Identification - Standard Components; Standard Parts List

37
Parts No. List
Part No. Part Name Q`ty in Use ltem No. Part No. Part Name Q`ty in Use ltem No.
2501114 S350 Gear Box Set (F&R) 2 SW-2501114
2501095 S350 Rear Hub Carrier Set (L&R) 1 SW-2501095
2501096 S350 Full Arm Holder Set (7pc) 1 SW-2501096
2501097 S350 Wing Stay Set with Bumper 1 SW-2501097
2501098 S350 Front Steering Knuckle Set (L&R) 1 SW-2501098
2501099 S350 R/F Insert, Brake, Throttle Linkage Linkage Holder 2 SW-2501099
2501100 S350 Pivot Ball Cup, Caster Insert Set 2 SW-2501100
2501116 SWORKz High Done Force Wing Set (BK)(Fit S350) 1 SW-2501116
2501121C S350/S350T Ball End Set with Shock Plastic Parts 2 SW-2501121C
2501122 S350 Settring Bellcrank Set with Servo Horn Set 1 SW-2501122
2501123 S350 Side Guard Set (L&R) 1 SW-2501123
2501529 S350 BX1/BR1 Plastic Chassis Brace Set 1 SW-2501529
2502036 S350 Series Rear Changable Plastic Lower Arm Plate with insert 1 SW-2502036
2502037 S350T Front Lower Arm Set 1 SW-2502037
2502038 S350T Rear Lower Arm Set 1 SW-2502038
2502039 S350T Front Upper Arm Set 1 SW-2502039
2502040-02 S350T Body Mount with Fuel Tank Ring-pull 1 SW-2502040-02
2503260-03 S35-3 Series Plastic Suspension Inserts Set 1 SW-2503260-03
2501469 S350 BE1Series Spur Gear Set(45T/46T/47T) 1 SW-2501469
2501471A S35-2E Center Di Mount Cover 1 SW-2501471A
2503220 S35-2E Plastic Chassis Brace Set (3pc) 1 SW-2503220
2503221BK S35-2E Plastic Radio Box/Battery Case Set 1 SW-2503221BK
220016-1 SWORKz 1/8 S35 E-series Plastic Steering Servo Mount 1 SW-220016-1
420010 Antenna Tube 1 SW-420010
250028 S350T Speed Rhinocero Body Shell 1 SW-250028
320003 Di. Bevel Gear 18T 6 SW-320003
320003 Di. Bevel Gear 10T 12 SW-320003
330013 Bevel Gear Shaft 6 SW-330013
330014A Front/Rear Di. Outdrive 4 SW-330014A
330015 Pin M2.2x9.9mm 6 SW-330015
330017 Center Di. Outdrive 2 SW-330017
330091A Settring BellcrankPlate 1 SW-330091A
330103 Front/Rear Lower Arm HingPin 4 SW-330103
330110 CVD Join 6 SW-330110
330111 Pin M2.5x14.8mm 6 SW-330111
330112 CVD Axle 4 SW-330112
330113 Servo Saver Shaft 2 SW-330113
330114A S350 Servo Saver Post (HC) 1 SW-330114A
330117A S350 Series Knuckle Pivot Ball Washer(GM) 2 SW-330117A
330118A S350 Series Knuckle Pivot Ball Nut(GM) 4 SW-330118A
330119 Front Upper Arm HingPin 2 SW-330119
330122A S350 Wheel Nut (HC) 4 SW-330122A
330124 Pin M3.0x16.8mm 4 SW-330124
330125 Rear Upper Sus. Arm Ball Stud 4 SW-330125
330127 Steering Linkage Ball Stud 7mm 4 SW-330127
330131A S350 Shock Spring Adjust Nut (GM) 4 SW-330131A
330134 Shock Ball Stud 12 SW-330134
330114A Servo Saver Nut(GM) 1 SW-330114A
330136 Sway Bar Ball Stud 4 SW-330136
330138A S350 EVO Aluminum Shock Cap Stud 4 SW-330138A
330139A S350 Shock Cap (GM) 4 SW-330139A
330160 S-System Pinion Gear 13T 2 SW-330160
330164 Crown Gear 43T 2 SW-330164
330218 BK1 EVO Shock Body (L) 2 SW-330218
330219 BK1 EVO Shock Body(S) 2 SW-330219
330220 BK1 EVO 4mm Shock Shaft ( L) 2 SW-330220
330221 BK1 EVO 4mm Shock Shaft (S) 2 SW-330221
330222A S350 EVO Shock Seal Cap (GM) 4 SW-330222A
210032 BK1 EVO Shock Seal Washer 3.6X7X2.5mm 4 SW-210032
210032 BK1 EVO Shock Seal Washer 3.6X7X1mm 4 SW-210032
330226 BK1 EVO Steering Knuckle Plate (L) 1 SW-330226
330226 BK1 EVO Steering Knuckle Plate (R) 1 SW-330226
330246 BE1 Motor Gear 16T 1 SW-330246
330249A S350 Series BK1 EVO Servo Saver Steering Plate (GM) 1 SW-330249A
330251 S350 BX1/BR1 Steering Plate Bushing 2 SW-330251
330252 Steering Knuckle Pivot Ball Turnbuckle 4 SW-330252
330266 BK1 EVO Aluminum Changable Rear Lower Arm Plate (FC USE) 1 SW-330266
330267A S350 EVO Aluminum Rear Lower Arm Holder (FC USE)(GM) 1 SW-330267A
330401 Rear Hub Carriers Hing Pin with Nut 2 SW-330401
330439 BK1 EVO Shock Piston 1.3mmX5 Holes 4 SW-330439
330458 S350T Rear Upper Arm Turnbuckle M5x72mm 2 SW-330458
330459 S350T Steering Linkage Turnbuckle M4x75mm 2 SW-330459
330454 S350T Drive Shaft L130mm 4 SW-330454
330501A S350T S-Pinion Gear 10T (suit only for SW-330502A) 2 SW-330501A
330502A S35-T Truggy Crown Gear 46T (Fit for SW-330650/330501A) 2 SW-330502A
330568 S350 Buggy Series Aluminum Center Di. Mount 1 SW-330568
330642 S35 Series Adjust Front Lower Arm Plate 1 SW-330642
330693 S35-2E Center Motor Mount 1 SW-330693
330694 6mm Ball Stud 1 SW-330694
330697 S35-2E Rear Drive Shaft (S) 1 SW-330697
330699B S35-2E/3E Center Main Drive Shaft (L) 1 SW-330699B
330776 S35-3 Series Servo Saver Nut 1 SW-330776
330814A S35-2E/ZEUS Series EP T7075 Main Chassis 1 SW-330814A
330815A S350T/ZEUS T7075 Sport Front Shock Tower 1 SW-330815A
330816A S350T/ZEUS T7075 Sport Rear Shock Tower 1 SW-330816A
330827 S350 Sport Buggy Series Aluminum Servo Saver Steering Plate 1 SW-330827
330830 S350 Sport Buggy Series Aluminum Rear Lower Arm Holder 1 SW-330830
400002 O-ring S5 6 SW-400002
400005 Shock Spring Adjust Nut O-Ring 4 SW-400005
400011A BK1 EVO Soft Shock Seal O-ring 3.8x2mm 8 SW-400011A
400009 Shock Boot (L) 2 SW-400009
400010 Shock Boot (S) 2 SW-400010
410031 S350 Seies Hex-Cell Shock Bladder 4 SW-410031
420010 Antenna Cup 1 SW-420010
250028 S350T Clean Body Shell Window Mask 1 SW-250028
600002 GEAR GREASE(5g) 1 SW-600002
610002 Di. Gasket (0.5T) 3 SW-610002
101010A M3 Countersunk Washer(GM) 4 SW-101010A
101004 Washer 3.5X10X0.2mm 12 SW-101004
101014A M3 Pivot Ball Bushing(GM) 1 SW-101014A
101015 M5x8xT0.4mm 5 SW-101015
101016 M5x8xT0.8mm 1 SW-101016
101018 SHIM 13x16x0.2mm 6 SW-101018
101019 SHIM 6.0x10.0x0.2mm 2 SW-101019
101020A 3mm Countersunk Washers (RD) 2 SW-101020A
101021 M3x8xT0.8mm 5 SW-101021
101022 M3.4x6xT0.5mm 4 SW-101022
103001 M3 Nut Lock 20 SW-103001
103003A Flange M3 Nut Lock (GM) 4 SW-103003A
103004 M2.5mm Nut Lock 2 SW-103004
104001 M5x4mm Set Screw 6 SW-104001
104004 M3x3mm Set Screw 12 SW-104004
104005 M3x4mm Set Screw 4 SW-104005
104007 M4x8mm Set Screw 4 SW-104007
104008 M4x4mm Set Screw 5 SW-104008
105001 M3x8mm Cap Screw 1 SW-105001
105004 M2.6x6mm Cap Screw 11 SW-105004
105005 M3x12mm Cap Screw 6 SW-105005
105006 M3x28mm Cap Screw 4 SW-105006
105011 M3x23mm Cap Screw 2 SW-105011
106001 M3x8mm Hex Soket OH/TP Screw 2 SW-106001
106002 M3x10mm Hex Soket OH/TP Screw 7 SW-106002
106003 M3x16mm Hex Soket OH/TP Screw 6 SW-106003
106005 M3x15mm Hex Soket OH/TP Screw 13 SW-106005
106006 M3x20mm Hex Soket OH/TP Screw 3 SW-106006
106007 M3x12mm Hex Soket OH/TP Screw(HT) 7 SW-106007
106008 M3x12mm Hex Soket OH/TP Screw 8 SW-106008
106009 M3x25mm Hex Soket OH/TP Screw 4 SW-106009
106010 M3x6mm Hex Soket OH/TP Screw 33 SW-106010
106013 M2.5x8mm 1.5mmHex Soket OH/ST Screw 4 SW-106013
106018 M3x3mm Hex Soket OH/TP Screw 2 SW-106018
106021A S35 Series M4x10mm Hex Soket OH/TP Set Screw 4 SW-106021A
108001 M3x12mm FH/ST HEX Screw 22 SW-108001
108003 M3x10mm FH/ST HEX Screw 26 SW-108003
108006 M3x8mm FH/ST HEX Screw 29 SW-108006
108008 M3x35mm FH/ST HEX Screw 4 SW-108008
108009 M3x20mm FH/ST HEX Screw 4 SW-108009
108010 M4x10mm FH/ST HEX Screw 2 SW-108010
108011 M4x12mm FH/ST HEX Screw 4 SW-108011
108012 M4x16mm FH/ST HEX Screw 8 SW-108012
108013 M4x8mm FH/ST HEX Screw 1 SW-108013
108014 M3x3mm FH/ST HEX Screw 4 SW-108014
108015 M3x16mm FH/ST HEX Screw 2 SW-108015
108019 M2.6x6mm FH/ST HEX Screw 22 SW-108019
115003 Tornado Clutch Spring 3 SW-115003
330114A Servo Saver Spring 1 SW-330114A
115005 Rear Sway Ball 2.8mm 1 SW-115005
115008 Front Sway Ball 2.3mm 1 SW-115008
115019 Body Clip 3 SW-115019
210029A S350 Shock Spring S (1.5mm x P14)(SB) 2 SW-210029A
210029A S350 Shock Spring L (1.5mm x P14)(SB) 2 SW-210029A
116004 Ball Bearing 6x10x3mm 4 SW-116004
116006 Ball Bearing 8x16x5mm 14 SW-116006
116010 Ball Bearing 5x10x4mm 2 SW-116010
116012 Ball Bearing 15x21x4mm 4 SW-116012
117003 Flange Ball Bearing 3x6x2.5mm 6 SW-117003
