SWorkz ZEUS - Page 8

8
4
3
BAG
C
116006
330017
320003
400002
330015
108003
320004 330013
610002
108003
101004
101004
108007
108007
101004
101004
2501469-01 (45T)
2501469-02 (46T)
2501469-03 (47T)
210002A
116006
330017
330241
330015
320003
400002
108003
M3x10mm FH/ST HEX Screw
x4
116006
Ball Bearing 8x16x5mm
x2
330015
Pin M2.2x9.9mm
x2
400002
O-ring S5 4.8X1.5
x2
101004
Washer 3.5X10X0.2mm
x4
330013
Bevel Gear Shaft
x2
Fill the
di󰀨erentials
with Oil up to
80% full.
Use SWORKz
Di󰀨. Oil
7000cps for
the center
Di󰀨.
Apply a light coat of grease
to the o-ring, then slide it over
the outdrive shaft and place it
in the di󰀨 case.
Insert the pin through the hole
of the out drive.
320004
108007
M3x6mm FH/ST HEX Screw
x4
