SWR 750x Operating Instructions

750x • 7
750x – FRONT PANEL FEATURES
• Dual independent input jacks compatible with both passive and active instruments
• Preamp Gain control with red LED clip indicator
• Aural Enhancer control
• Overdrive Activator Switch (illuminated red when engaged)
• Overdrive “Drive” Control
• Overdrive Level Control
• SubWave™ Activator Switch (illuminated blue when engaged)
• SubWave™ Level control
• Bass control (with Pull Turbo function)
• Midrange Level control
• Midrange Frequency control
• Treble control (with Pull Transparency function)
• Effects Blend control
• Variable Limiter
• Limiter Active green LED indicator
• Master Volume control
• Speaker On/Off Switch
• Illuminated Neon Power On/Off switch
750x – REAR PANEL FEATURES
• XLR Pad (Level) control
• XLR Output jack
• XLR Mode switch (Direct, Direct + EFX, Line)
• Ground/Lift switch for XLR Output jack
• Side-Chain Effects Loop (Effects Send and Effects Return 1/4" jacks)
• Tuner Out Jack
• Preamp Out Jack
• Overdrive Activator Footswitch jack
• SubWave™ Activator Footswitch jack
• Fan Mode switch
• Stereo Headphones Jack
• Two Speakon and two 1/4" Speaker Output jacks
• Speaker Fuse (3AG, 10-amp fast-blo)
• Line Fuse
• AC Power Cord Receptacle
ELECTRICAL SPECIFICATIONS
Note: All measurements were taken with a line voltage of 120VAC. All noise specifications are
“unweighted.” All voltages and watts are “RMS.” All measurements are taken with tone controls
set flat, Aural Enhancer at minimum.
Power Ratings (minimum)
750 Watts @ 4 ohms
450 Watts @ 8 ohms
