750x – FRONT PANEL FEATURES
• Dual independent input jacks compatible with both passive and active instruments
• Preamp Gain control with red LED clip indicator
• Aural Enhancer control
• Overdrive Activator Switch (illuminated red when engaged)
• Overdrive “Drive” Control
• Overdrive Level Control
• SubWave™ Activator Switch (illuminated blue when engaged)
• SubWave™ Level control
• Bass control (with Pull Turbo function)
• Midrange Level control
• Midrange Frequency control
• Treble control (with Pull Transparency function)
• Effects Blend control
• Variable Limiter
• Limiter Active green LED indicator
• Master Volume control
• Speaker On/Off Switch
• Illuminated Neon Power On/Off switch
750x – REAR PANEL FEATURES
• XLR Pad (Level) control
• XLR Output jack
• XLR Mode switch (Direct, Direct + EFX, Line)
• Ground/Lift switch for XLR Output jack
• Side-Chain Effects Loop (Effects Send and Effects Return 1/4" jacks)
• Tuner Out Jack
• Preamp Out Jack
• Overdrive Activator Footswitch jack
• SubWave™ Activator Footswitch jack
• Fan Mode switch
• Stereo Headphones Jack
• Two Speakon and two 1/4" Speaker Output jacks
• Speaker Fuse (3AG, 10-amp fast-blo)
• Line Fuse (3AG, 7-amp slo-blo in the U.S.)
• AC Power Cord Receptacle
ELECTRICAL SPECIFICATIONS
Note: All measurements were taken with a line voltage of 120VAC. All noise specifications are “unweight-
ed.” All voltages and watts are “RMS.” All measurements are taken with tone controls set flat, Aural
Enhancer at minimum.
Power Ratings (minimum)
850 Watts @ 2.6 ohms
750 Watts @ 4 ohms
450 Watts @ 8 ohms
2 • 750x OWNER’S MANUAL
