. Cylinder Head / Valve

6-1

Mechanism Diagram €€€€€€€€€€€€€€€€€€€€€€€€€€€ 6-1

Precautions in Operation €€€€€€€€€€€€€€€€€€€ 6-2

Troubleshooting€€€€€€€€€€€€€€€€€€€€€€€€€€€€€€€€€€ 6-3

Cylinder Head Removal€€€€€€€€€€€€€€€€€€€€€€ 6-4

Cylinder Head Disassembly€€€€€€€€€€€€€€€ 6-6

Cylinder Head Inspection€€€€€€€€€€€€€€€€€€€ 6-8

Valve Stem Replacement€€€€€€€€€€€€€€€€€€€ 6-10

Valve Seat Inspection and Service €€€ 6-11

Cylinder Head Reassembly€€€€€€€€€€€€€€€ 6-13

Cylinder Head Installation€€€€€€€€€€€€€€€€€ 6-14

Valve Clearance Adjustment€€€€€€€€€€€€€ 6-16

Mechanism Diagram

0.7~1.1kgf-m

1.0~1.4kgf-m

1.0~1.2kgf-m

3.6~4.0kgf-m
