16. Steering / Front Wheel / Front Cushion
16-1
Mechanism Diagram .......................... 16-1 Front Wheel.........................................16-6
Precautions in Operation .................. 16-2 Front Cushion.....................................16-10
Troubleshooting................................. 16-2 Front Fork / Steering Stem ................16-11
Steering Handlebar ............................ 16-3
Mechanism Diagram
2.4~3.0 kgf-m
4.0~5.0 kgf-m
2.4~3.0 kgf-m
5.0~7.0 kgf-m
0.15~0.3 kgf-m
0.2~0.3 kgf-m
1.0~2.0 kgf-m
