5. Fuel Injection System
5-24
Air Cleaner
Remove the air cleaner cover (8 screws).
Remove the air cleaner element (4 screws).
Caution
● The air cleaner is paper-base; please
blow it clean with compressed air. Don’t
use water or other solvent
● Replace it with new one if the dirt cannot
be removed.
Installation
Install in the reverse order of removal.
8 screws
4 screws
Element
