2 of 4
QUICK START GUIDE: ARC-2e
www.symetrix.co | +1.425.778.7728
The RJ45 connectors labeled “ARC” are only for use with the ARC series of remotes.
DO NOT plug the ARC connectors on Symetrix products into any
RJ45 connector labeled “DANTE” or “ETHERNET”
.
The “ARC” RJ45 connectors on Symetrix products can carry anywhere from 6 to 24 VDC which
can damage Dante and Ethernet circuitry.
ARC
PRIMARY
SECONDARY
DANTE NETWORK AUDIO
ARC-2e
DOWN
UP
MENU
ARC-2e
DOWN
UP
MENU
ARC-2e
DOWN
UP
MENU
ARC-2e
DOWN
UP
MENU
ARC
ETHERNET
To Next Page
