Synergy 516 - Page 7

Left
Right
x17
x18
Apply BLUE threadlocker to all frame
bolts. Do not fully tighten bolts at this
step.
100-266
M2.5x6 Socket Head
100-266
M2.5x6 Socket Head
01 | INTRODUCTION
02 | FRAME
03 | LANDING GEAR
04 | BELT TENSION ARM
05 | MAIN DRIVE
06 | BOOM INSTALLATION
07 | TAIL ASSEMBLY
08 | SETTING BELT TENSION
09 | SWASH PLATE
10 | CYCLIC SERVOS
11 | ANTI-ROTATION GUIDE
12 | TAIL SERVO
13 | MAIN HEAD
14 | PITCH LINKAGES
15 | MOTOR INSTALLATION
16 | BATTERY TRAY & CANOPY
17 | BLADE INSTALLATION
18 | COMPLETE MODEL
02 | FRAME
7
Rev 1.0M
FRAME BOLTS
