Synergy E5 - Page 18

Canopy Mount Install - Left Frame Side
101-310 M3x10 Button Head
100-351 M3 Nylock Nut
21mm Front Canopy Mount
See Page 4
17mm Rear Canopy Mount Assembly
See Page 4
Note - Button Head fits into large frame hole, mounts will fit flush against frame.
305-101 E5 Frame Spacer
101-306 M3x6 Button Head
Page 16
