3.5.2 Description of the external connections
Your device will not incorporate all of the following connectors (see
Ä
Chapter 3.3 “Technical data for the device” on page 13).
= 9-pole Sub-D socket for connecting serial devices
Fig. 10: Serial connection (RS
‑
232)
= 24-pole DVI socket for connecting to the basic computer
Fig. 11: DVI socket with pinout
= 19-pole HDMI socket for connecting to the basic computer
Fig. 12: HDMI socket with pinout
= 15-pole HD-D "VGA" socket for connecting basic computer
Fig. 13: VGA socket with pinout
= 4-pole USB socket (type A) for connecting components:
n VoIP hardware components and/or
n touchscreen and/or
n keyboard
Fig. 14: USB socket with pinout
Serial connection (RS‑232)
DVI port
HDMI port
VGA port
USB connection
Product description
External connectors > Description of the external connections
WAVE 221 PC - Industrial PC
17
