This document describes the assembly and features of a wall-mounted cabinet, identified by the product number 7365413COM.

Function Description

This device is a wall-mounted cabinet designed for storage. It features multiple compartments, including three main sections with doors and adjustable shelves, providing versatile storage solutions for various items. The cabinet is intended to be securely mounted to a wall, offering an elevated storage option that can help save floor space.

Important Technical Specifications

The cabinet is designed to support specific maximum loads:

Top surface: 0 lbs (0 kg)
Each adjustable shelf: 30 lbs (13.6 kg)
Bottom shelf (right section): 35 lbs (15.8 kg) Exceeding these load limits could cause sagging, instability, product collapse, and/or serious injury. The unit is constructed using various components, including end panels, partitions, top and bottom panels, back rails, back panels, doors, and adjustable shelves. Assembly requires specific hardware such as cam locks, cam bolts, shelf supports, screws, steel dowels, door bumpers, and hinges. The overall dimensions and specific material composition are not explicitly detailed in the provided pages but are implied by the assembly instructions. The product is certified to comply with the CPSC Ban on Lead-Containing Paint (16 CFR 1303).

Usage Features

The cabinet offers several usage features:

Adjustable Shelves: The inclusion of adjustable shelves (parts F and G) allows users to customize the internal storage space to accommodate items of different heights. This flexibility enhances the utility of the cabinet for diverse storage needs.
Doors: The cabinet features three doors (part H) that enclose the main storage compartments, keeping contents out of sight and protected from dust. The doors are equipped with hinges that allow for adjustment after installation.
Wall Mounting: The cabinet is designed for wall mounting, which is a key feature for optimizing space in rooms. The mounting process involves locating studs in the wall and securing the cabinet using wall hangers (part K) and screws (part 7).
Cam Lock System: The assembly primarily utilizes a cam lock fastening system, which is a common feature in ready-to-assemble furniture. This system allows for relatively straightforward and secure connections between panels.
Door Adjustment: The hinges are adjustable, allowing for fine-tuning of the door position after installation. This feature helps ensure proper alignment and smooth operation of the doors, compensating for minor variations in assembly or wall conditions. Adjustments can be made to move the door left/right, up/down, and in/out (side view).

Maintenance Features

The manual provides general maintenance guidelines for the cabinet:

Cleaning: To clean the product, users should use a soft cloth and a mild polish. Abrasive cleaners or chemicals should be avoided as they can damage the finish.
Relocation: When moving the furniture, it is recommended to lift it with two people and carry it to the new location. Dragging or pushing the unit can cause damage.
Hardware Tightening: Periodically, it is advised to check and tighten all fasteners to ensure the stability and safety of the cabinet.
Replacement Parts: If any parts are missing or damaged, users are instructed to contact customer service for replacements. This ensures the longevity and proper functioning of the unit.
Load Management: Adhering to the maximum load limits for each shelf and the top surface is crucial for maintaining the structural integrity of the cabinet and preventing damage or injury.
Regular Inspection: The warning section implies that regular inspection for loose screws or drawers is important to prevent potential hazards.

Safety Warnings

The manual includes several safety warnings:

Tip-Over Hazard: The unit can tip over causing severe injury or death. Users are warned to anchor the unit to a wall stud or wall.
Climbing Hazard: Children should not be allowed to climb on the unit.
Weight Distribution: Heavy items should be placed on lower shelves or drawers to improve stability.
Assembly Instructions: Users must read and follow all assembly instructions carefully to ensure safe and correct assembly.
Professional Assistance: If unsure about any part of the assembly, users are advised to seek professional assistance.
Damaged Parts: Do not use the product if any parts are missing, damaged, or broken.
Tool Usage: Only use the tools recommended in the manual.
Work Area: Assemble the unit in a clean, spacious area, preferably on a carpet or blanket, to prevent damage to the product or floor.
Fastener Tightening: Do not overtighten fasteners.
Lead Paint Compliance: The product complies with CPSC Ban on Lead-Containing Paint, ensuring it is safe for use in households.

System Build 7365413COM - Page 9
