STEP
7
Loosen screw C
Adjust door.
Tighten screw C
*side view
Loosen screw C
Turn screw B to
move door.
Tighten screw C
Loosen screw A
Adjust door.
Tighten screw A
(x4)
#17300
(x1)
#A55015
(x2)
#A52700
(x2)
#A11145
B
A
C
G
H
optional
Attach the doors to the
unit and make
adjustments if needed as
shown in the detail.
Attach the handle and
lock as shown.
