SystemAir Topvex SR03

Mainmenuitem
Sub-menuitem1Sub-menuitem2
Explanations
Flowcontrol
EAF
Setp1/1:1100
m³/h
Setp1/2:550
m³/h↓
Setthenormal(1/1)and
reduced(1/2)airowforthe
extractairfan.
Outdoor
comp.Setp.1
–20°C=10m³/h
0°C=0m³/h
Act.Comp:0
m³/h
SettheEAFairow
compensationforthesettable
outdoortemperature.The
outdoorcompensationislinear
andissetusingtwoparameter
pairswhichgivethevalueofthe
compensationattwodifferent
outdoortemperatures.The
compensationcanbepositive
ornegative.
Showstheactualairow
compensation.
Pressure
controlSAF
Actual:Pa
Setp.:Pa
Theactualexternalpressure
andsetpointforthesupplyair
fan.
Onlyvisibleiftheunitis
conguredfor"Pressure
control"(VAV)
Pressure
controlSAF
Setp1/1:250
Pa
Setp1/2:100
Pa
Settheexternalpressureset
pointfornormalspeed(1/1)
andreducedspeed(1/2)forthe
supplyairfan.
Outdoor
comp.Setp.1
—20°C=0Pa
10°C=0Pa
Act.Comp:0
Pa
SettheSAFpressure
compensationforthesettable
outdoortemperature.The
outdoorcompensationislinear
andissetusingtwoparameter
pairswhichgivethevalueofthe
compensationattwodifferent
outdoortemperatures.The
compensationcanbepositive
ornegative.
Showstheactualpressure
compensation.
Pressure
controlEAF
Actual:Pa
Setp.:Pa
Theactualexternalpressure
andsetpointfortheextractair
fan.
Onlyvisibleiftheunitis
conguredfor"Pressure
control"(VAV).
TopvexSR/TR03,SR/TR04,SR/TR06OperationandMaintenanceInstructions
206902
13
SystemairAB
