Mainmenuitem
Sub-menuitem1Sub-menuitem2
Explanations
→Freecooling
Freecool
active:No
Outd.temp
activation
22°C
Setfreecoolingactiveto"Yes
orNo.
Settheloweroutdoorday
temperaturelimitforthe
activationofthefreecooling
function.Thetemperatureof
thepreviousdayneedstobe
overthesettemperaturein
orderactivatethefreecooling
function.
Outd.temp
night
High:15.0°C
Low:5.0°C
Roomtempmin.
18°C
Settheupperoutdoornight
temperaturelimitforthe
activationofthefreecooling
function.
Settheloweroutdoornight
temperaturelimitforthe
activationofthefreecooling
function.
Setthelowerroomtemperature
limit.Thetemperatureneedsto
beabovethisvalueforthefree
coolingfunctiontostayactive.
Ifnoroomsensorareconnected
extractairisvalid.
Hourfor
start/stop
Freecooling
Start:0
Stop:7
Setthestartandstoptimefor
thefreecoolingfunction
ForexampleStart:0and
Stop:6
meansthatthefreecooling
sequenceisactivebetween
00.00and06.00h.
Timetoblock
heatoutput
afterFree
cooling
60min
Setthedelayinminutesfrom
thetimewherethefreecooling
sequencehasstoppeduntila
possibleheatingsequenceis
initiated,i.e.howlongacooler
roomtemperaturethanset
temperaturecanbeaccepted
Fanoutputwhen
freecooling
SAF:0%
EAF:0%
Setthefanspeedinpercentage
ofthenormalspeedforeach
fanindividuallyduringthefree
coolingsequence
Outdoorsensor
placedin
intakechannel
(intakeduct)
No
Setiftheoutdoorsensoris
placedintheintakeductornot.
ChoosebetweenNoandYes
PresetisNo.
TopvexSR/TR03,SR/TR04,SR/TR06OperationandMaintenanceInstructions
206902
20
SystemairAB
