SystemAir Topvex SR04 User Manual

Commissioning
|
15
Main menu item
Sub-menu item 1 Sub-menu item 2 Explanations
P1 heating
Auto
Set the pump control for the
heating coil to Auto, On or Off
P1 exchanger
Auto
P1 cooling
Auto
Set the pump control for the
cooling coil to Auto, On or Off
Fire damper
Auto
Set the Fire damper to Auto, Open
or Close
Note:
Needs to be activated in
order to be visible here
Configuration of fire
damper functions are made
at Administrator level
Outdoor air
damper
Auto
Set the Outdoor air damper to
Auto, Open or Close
Exhaust air
damper
Auto
Set the Exhaust air damper to
Auto, Open or Close
Extra ctrl unit
Auto
Manual set: 0.0
Set the extra control unit to Auto,
Manual or Off.
Extra sequence Y4
Auto
Manual set: 0.0
Set the Extra sequence to Auto,
Manual or Off
Only visible for Topvex SC units
Extra sequence Y5
Auto
Manual set: 0.0
Set the Extra sequence to Auto,
Manual or Off
Not used in default setting.
→ Settings
In this menu group the settings for
the activated functions are
available. Depending on which
choices have been made in the
configuration menu some of the
possible alternatives may not be
displayed.
→ Control temp
Supply air control
P-band: 33.0°C
I-time: 100.0 sec
Set P-band and I-time for the
Supply air control function
Note:
See Corrigo manual-
Ventilation application for
more information.
Extract air control
P-band: 100.0°C
I-time: 300.0 sec
Set P-band and I-time for the
Extract air control function
Note:
See Corrigo manual-
Ventilation application for
more information.
