Commissioning
|
17
Main menu item
Sub-menu item 1 Sub-menu item 2 Explanations
→ Restore alarm
Reset the service alarm (filter
alarm).
Restore factory
settings: No
Restore user
settings: No
In this menu, it is possible to
restore all parameters to their
factory settings or to the user
settings they were saved as
earlier.
Select Yes or No
Save user
settings
No
The current configuration can be
saved in a separate memory area
and can later be restored using the
previous menu, Restore user
settings. Select Yes or No
Darker gray area, log in to
“Administrator level”
code 3333
→ Configuration
→
Inputs/Outputs
Setup for inputs and outputs.
→
Sensor settings
Setup of sensor types and control
range.
→
Control function
Control function
Mode:
Cascade extract
ctrl
Set type of temperature control
function you want the unit to
operate under. Choose between
Room control, Cascade
extract ctrl, Outd comp
room, Outd comp extr air,
Supply air control, Outdoor
comp. supply
Extract/supply air
→(possible to switch between the
two depending on outdoor temp.),
Room/supply air →(possible to
switch between the two depending
on outdoor temp.),
Fan control
Extra control
unit
Mode extra unit
Running if units
runs
The extra control circuit can be
configured to be either constantly
active, only when the regular
control circuit is active, ceiling fan,
saturation or run in defrosting.
Heating or cooling for extra unit is
also changeable.
→ Extra sequency
Y4
Topvex SC:
Mode extra sequence
Y4
Active w cool recov
Only active for Topvex SC
Can be configured to one of the
following alternatives: Active,
Active with cooling
recovery, Active with
enthalpy control and Active
with both cooling recovery
and enthalpy control.
→ Extra sequency
Y5
Extra sequence Y5 can be
configured to Active or Not
active.
→
Pump control
P1–Heating
P1–Cooling
Set parameters for pump control.
If, for any of the control circuits, no
output is configured for pump
control these settings will be
ignored.
124455 | A003
