Commissioning
Main menu item
Sub-menu item 1 Sub-menu item 2 Explanations
Outdoor comp.Setp.
–20°C = 0 m³/h
0°C = 0 m³/h
Act. Comp: 0
Set the SAF airflow compensation
for the settable outdoor
temperature. The outdoor
compensation is linear and is set
using two parameter pairs which
give the value of the compensation
at two different outdoor
temperatures. The compensation
can be positive or negative.
Shows the actual airflow
compensation.
Flow control EAF
Actual: xxx m³/h
Setp.:xxx m³/h→↓
Airflow for the extract air fan
(constant airflow control).
Only visible if the unit is
configured for “Flow control”
(CAV).
Flow control EAF
Setp 1/1: 1100 m³/h
Setp 1/2: 550 m³/h↓
Set the normal (1/1) and reduced
(1/2) airflow for the extract air fan.
Outdoor comp.Setp.
–20°C = 0 m³/h
0°C = 0 m³/h
Act. Comp: 0
Set the EAF airflow compensation
for the settable outdoor
temperature. The outdoor
compensation is linear and is set
using two parameter pairs which
give the value of the compensation
at two different outdoor
temperatures. The compensation
can be positive or negative.
Shows the actual airflow
compensation.
Pressure control
SAF
Actual: Pa
Setp.: Pa→↓
The actual external pressure and
set point for the supply air fan.
Only visible if the unit is
configured for "Pressure control"
(VAV)
Pressure control
SAF
Setp 1/1: 200 Pa
Setp 1/2: 100 Pa↓
Set the external pressure set point
for normal speed (1/1) and
reduced speed (1/2) for the supply
air fan.
Outdoor comp.Setp.
1
—20°C = 0 Pa
10°C = 0 Pa
Act. Comp: 0 Pa
Set the SAF pressure compensation
for the settable outdoor
temperature. The outdoor
compensation is linear and is set
using two parameter pairs which
give the value of the compensation
at two different outdoor
temperatures. The compensation
can be positive or negative.
Shows the actual pressure
compensation.
Pressure control
EAF
Actual: Pa
Setp.: Pa→↓
The actual external pressure and
set point for the extract air fan.
Only visible if the unit is
configured for "Pressure control"
(VAV).
Pressure control
EAF
Setp 1/1: 200 Pa
Setp 1/2: 100 Pa↓
Set the external pressure set point
for normal speed (1/1) and
reduced speed (1/2) for the supply
air fan.
