Page 2

FIG 3

FIG 7

FIG 8

FIG 9

FIG 4 FIG 6FIG 5

STEP 5

5) See Figure 4 for hardware conﬁgured orinetation.

STEP 6

6) Place bottom billet overlay into position.

Adjust side to side or up / down and in/out if needed. Align evenly on all side,

and carefully press into place so that the overlay hugs closely inside opening.

SEE FIGURE 3

SEE FIGURES 4 & 5

STEPS 7 & 8

7) Press screw through factory grille so that “Toggle Wing“ nut can catch on the

back side of factory grille.

8) Use a Phillips Head screwdriver to tighten screws and secure grille overlay into place.

Using an an extra long ﬂat head screwdriver to hold toggle wings while tightening down

the screws will help.

SEE FIGURE 6

STEPS 9 - 10

Place top billet overlay into position. Fit into place and repeat steps for proper look /

alignment. Repeat steps for hardware install.

10) Now, identify where top bracket hangers tabs locate. Use a Drill to run down

provided screws and tighten and secure upper billet overlay.

SEE FIGURES 7 - 9

BILLET SERIES Grille

Main grille - #21267 / #21267B

GRILLE INSTALL - Continued

GRILLE INSTALL complete

Grille INSTALL on Vehicle

2015 CHEVROLET COLORADO
