T-Rex Moller 2 User Manual

CONTROL YOUR MØLLER 2
Møller 2 has 5 controls: TONE, GAIN, MIX, LEVEL and BOOST.
TONE adjusts a broad range of frequencies and provides great tonal
control.
GAIN controls overall distortion.
MIX lets you dial in the perfect balance between distorted and non-
distorted signal. Roll the mix knob back a bit, and your clean signal
starts to get through, meaning that if you pick lightly, or roll back the
volume on your guitar, you get a stunning clean/softly clipping sound
that retains all the feel and dynamics of your original tone, only
bigger, louder and richer. Rolled all the way up and with distortion
maxed too, the pedal sounds just like an old tube amp on full volume.
LEVEL controls master volume.
BOOST controls the amount of boost, from 0-20 db. The boost
function lets you dial in a solo level, whether the overdrive circuit is
activated or not.
TECHNICAL SPECIFICATIONS
Input Impedance@1KHz Higher than 1M Ohm
Output Impedance@1KHZ Lower than 1K Ohm
Power supply 9V DC (T-Rex FuelTank)
Minimum Power supply Voltage 8,5V DC
Maximum Power supply Voltage 12,5V DC
Current Draw @ 9V DC 16 mA
Maximum Input signal Vp/p 2,5Vp/p
Battery Type 9 V battery 6F22
Battery Life 5 to 8 Hour
External connectors Input Jack. Output Jack, 9V DC Jack
Controls On/Off, Boost On/Off, Level, Gain,
Tone, Mix, Boost, Bass Boost
Pedal size incl. knobs (W x H x D) 100 x 55 x 120 mm
3,9 x 2,2 x 4,7 inch
Weight excl. battery and packaging 0,345 kg / 12,2 oz

T-Rex Moller 2 Specifications

General

Brand	T-Rex
Model	Moller 2
Category	Music Pedal
Language	English
