TECHNICAL SPECIFICATIONS
Input Impedance@1KHz Higher than 1M ohm
Output Impedance@1KHZ Lower than 1K ohm
Power supply 9V DC
Minimum Power supply Voltage 8V DC
Maximum Power supply Voltage 12,5V DC
Current Draw @ 9V DC 20 mA
Maximum Input signal Vp/p 1,5Vp/p
Battery Type 9 V battery 6F22
Battery Life 6 to 9 Hour
External connectors Input Jack, Output Jack, 9V DC Jack
Controls 2 x GAIN - 2 x LEVEL - 2 x TONE -
2 x BOOST - ON/OFF
Pedal size incl. knobs (W x H x D) 100 x 55 x 120mm
3,9 x 2,2 x 4,7 inch
Weight
(excl. battery and packaging) 0,350 kg / 12,3 oz
MUDHONEY II CONTROLS
Your Mudhoney II has 4 controls for each channel: GAIN, LEVEL, TONE
and BOOST.
The GAIN knob is the most important control on your Mudhoney II. The
more you turn it up, the more overdrive gain you get. Make sure to set
the GAIN differently for the 2 Mudhoney II channels, so you can switch
between the channels for different levels of distortion.
Use the LEVEL knob to set the overall output volume from the pedal. At
12 o’clock your output is the same as your input volume. Turning it all
the way up (clockwise) will boost your output signal by 15 dB.
The TONE knob lets you control the top end, or “edge”, of your signal
without compromising sonic quality. Try setting it separately for each
channel to create your own signature overdrive and distortion sounds.
Use the BOOST switch to switch between moderate and high gain for
each channel separately.
