Taco LeakBreaker LB-075-H-1LF

ADDITIONAL & REPAIR PARTS
Product # Description
7240-LB1
LeakBreaker Sensor
Includes 3' of Additional Wire
7240-004RP Actuator
7240-005RP Control Box
7240-006RP Power Supply
7240-008RP Control Box with eLink (Wi-Fi)
PRODUCT SPECIFICATIONS
Maximum Static Pressure 300 PSI (2,100 kPa)
Maximum Shutoff Pressure 125 PSI (875 kPa)
Maximum Ambient
Temperature
135°F
Fluid Temperature Range 33° to 220°F, (1° to 105°C)
Service Potable water
Seat Leakage Drop-Tight Close-Off
Electrical
Input: 120VAC 60 HZ,
Output: 6VDC
600mA Power Supply or 4 AA
Batteries
Auxiliary Switch Rating
Class 2. 1Amp 24Volts
MATERIALS OF CONSTRUCTION
Control Panel
Body High Performance Engineered Polymer
Actuator
Body High Performance Engineered Polymer
Gears
High Performance Internally Lubricated
Engineered Polymer
Valve
Body Forged Brass
Stem Brass
Press Ring Brass
Ball Brass (Chrome Plated)
Seat Modified Teflon®
O-rings Viton®
5
4 7/8
2 1/8
3 1/2
4 3/8
7/8
3 1/8
1 9/16
DIMENSIONS (FOR REFERENCE PURPOSES)
