Tactix 488132 - Radio Mode; Listening Mode (LIS); Aux-In Mode; Troubleshooting and Specifications

RESPONSIBLE DISPOSAL:
This symbol indicates that this product should not be disposed of with general household waste. This applies
throughout the entire EU, In order to prevent any harm to the environment or health hazards caused by incorrect
waste disposal, the product must be handed in for recycling so that the material can be disposed of in a responsible
manner. When recycling your product, take it to your local collection facility or contact the place of purchase. They
will ensure that the product is disposed of in an environmentally sound manner.
SPECIFICATIONS:
Brand TACTIX
Radio FM 87.5-108 MHz (60 Preset channel)
Radio DAB 174-240MHz
Bluetooth 2402-2408 MHz
Batteries 1500mAh (xed inside)
Weight 375 g
Bluetooth version 4.2
Noise level Max 105 dB(A)
Size(w x h x l) 16x19x10cm, Earmus t size S, M, and L
Battery life* FM + BT+DAB Up to 15 hours
*Dependent on the make of battery and temperature
Shelf time: 3 years after production
Problem Cause Solution
Nothing is shown on the display The battery is empty. Charging the battery.
No sound The volume switch is in the OFF position Turn the volume switch clockwise
The audio source is not switched on Start playback on the external audio source
The audio cable is not connected properly Check that the audio cable is fully plugged in.
Wrong mode selected. Select FM (radio) or BT (Bluetooth)
Background noise The radio station is not tuned in correctly Adjust the frequency
Poor signal reception Change the batteries
RADIO MODE:
1.Power on the earmu and select Radio mode using the [Mode].
2.Then press the [LIS/Phone] to auto-scan for a FM radio station, the detected radio station will be saved to the device.
If you press the [LIS/Phone] again while scanning, it will stop current auto-scan.
3.Press [Select Down]/ [Select Up] to switch between saved radio stations.
4.Press [Mode] more than 3 seconds until there are”<“ ”>”beside the frequency, then press [Select Down]/ [Select Up]
for precise adjustment on the frequency by hand. Press [LIS/Phone] to conrm the adjustment and save it.
Note: Earmu Radio will hold the last used radio station to enjoy next time without searching.
LISTENING MODE (LIS):
1.In any mode, press [LIS/Phone] more than 3 seconds to start listen.
2.Adjust the volume as need on earmu by using the dial.
3.Press [LIS/Phone] again more than 3 seconds to end listen.
Note: Press to listen function will stop current Bluetooth/Radio if you start it, after ending listen function, earmu will go
back to last Bluetooth/Radio mode.
AUX-IN MODE:
1.Power on the earmu.
2.To use the Aux Input, plug a 3.5mm cable into the Aux-In port on earmu.
3.Adjust the volume at your device.
4.Draw the cable out, the earmu go to Bluetooth mode.
Note: 1. It will stop current Bluetooth/Radio if you plug the cable.
2. It can be used at power o status too, the volume can be adjusted on your device.
WARNING:
This ear-mu is provided with level-dependent attenuation. The wearer should check correct operation before use. If
distortion or failure is detected, the wearer should refer to the manufacturers’ advice for maintenance and replacement
of the battery. Warning-performance may deteriorate with battery usage. The typical period of continuous use that can
be expected from the ear-mu battery is 15 hours. The output of the level-dependent circuits of this hearing protector
may exceed the external sound level. The ear mus provides electrical audio input.
TROUBLESHOOTING GUIDE:
MANUFACTURER
Meridian International Co., Ltd.
1886 Laiyin Road, Songjiang , Shanghai, China
Tel: (021) 3763 3311 Fax: (021) 3763 3322, 3763 3355
www.meridianintl.com
DECLARATION OF CONFORMITY
Hereby, Meridian International Co., Ltd declares that the ear
mu with radio equipmentTAXTIX 488132is in compliance
with Regulation (EU) 2016/425 and Directive 2014/53/EU.
The full text of the EU declaration of conformity is available at
the following internet address:
http://www.meridianintl.com/website/company/News_detail.jsp?l-
mId=20&infoId=681&row_num=1&lmType=EN#
Tested and supervised by
PZT GmbH
An der Junkerei 48 F
D - 26389 Wilhelmshaven
Deutschland – Germany
notied body 1974
Model: 488132
Li-ion: 1500 mAh Input: 5V 1A
Meridian International Co., Ltd
1886 Laiyin Road, Songjiang
Shanghai, China
1974
FM Broadcast Radio Receiver Max sound level: 74.8 dB(A)
DAB Broadcast Radio Receiver Max sound level: 79.4 dB(A)
DAB+ Broadcast Radio Receiver Max sound level: 78.8 dB(A)
AUX-IN Max sound level: 72.8dB(A)
Bluetooth Max sound level: 72.6dB(A) Bluetooth Prole A2DP
Max sound level: 73.6dB(A)Bluetooth Prole HFP
Level Dependence(EN 352-4)
Criterion Level H= 110dB, M= 102 dB, L=90 dB
HML Values
Attenuation data
Frequencies in (Hz)
MF(dB)
SF(dB)
APV
63
12.6
3.5
9.1
125
11.1
3.3
7.8
250
14.4
2.1
12.3
500
20.2
2.0
18.2
1000
26.0
3.0
23.0
2000
26.8
3.8
23.0
4000
40.0
4.1
35.9
8000
41.5
4.9
36.6
H M L SNR
26 dB 21 dB 14 dB 24 dB
3 4
ENGLISH
