XT-1 Installation Manual 13-111 02, 2014-RO-012, 2014-04-30
Page 8 of 32
Figure 5 The XT-1 M20 cable gland with insert for 2 cables
Never remove or use the ventilating membrane (Figure 6, Pos. 2) on the back of the XT-1 for cable
connections.
Figure 6 XT-1 overview (Pos. 1 is ground screw connection, Pos.2 is ventilating membrane)
