USER MANUAL
TAIMEN company develops and manufactures underwater hunting
gear for sports and amateur spearfishing.
The prototype of the speargun series is an underwater competition
target shooting gun.
Solutions employed to create TAIMEN fishing gear are unique
nowadays.
TAIMEN company holds patents and certificates on the useful
model for gear manufacturing.
TAIMEN fishing gear provides comfortable and effective
underwater hunting.
New engineering solutions are proved effective by continuous tests
in swimming pools and natural conditions.
It is at the development and testing stage when the gear was highly
appreciated and received approval of experienced spearos.
PNEUMATIC SPEARGUN
SPEARGUN DESIGN
Picture 1.
1
Please, read the instructions of this user manual carefully. Improper
operation with the speargun may cause serious personal injury or death.
DANGER!
ATTENTION!
TAIMEN PVMR speargun overall view is presented at Picture 1.
The speargun consists of the following main parts and units:
Receiver assembly
1
2
3
4
5
6
7
8
9
10
11
12
PNEUMATIC SPEARGUNS ARE DESIGNED FOR
UNDERWATER HUNTING AND MUST ONLY BE USED WHEN
FULLY SUBMERGED UNDER WATER. FIRING IN THE AIR
CAUSES DAMAGE TO THE SPEARGUN.
PVMR
Handgrip with trigger mechanism
Power reducer
Safety catch
Line releaser
Snap hook
Revolving ring
Charging valve cap
Line
Spear
Line slide
Line slide holder
On the one end the line is attached to the speargun
with a snap hook (6), on the other end the line is attached
to the line slide (11).
