M2000-00

T2010 & T2015 HC05 Logic PCB

7.10.21

Ref Var IPN Description Ref Var IPN Description

IPN 220-01377-03

C500 016-08470-01 CAP ELECT SMD 6X4MM 47M 16V

C501 015-23680-08 CAP CER 0805 CHIP 680P 10% X7R 50V

C501A 018-14100-00 CAP 0603 CHIP 1N 50V X7R +-10%

C502 018-15100-00 CAP 0603 CHIP 10N 50V X7R +-10%

C503 018-15100-00 CAP 0603 CHIP 10N 50V X7R +-10%

C504 015-06100-08 CAP CER 1206 CHIP 100N 10% X7R 50V

C505 015-06100-08 CAP CER 1206 CHIP 100N 10% X7R 50V

C506 018-12220-10 CAP 0603 CHIP 22P 50V NPO +-1%

C507 018-12220-10 CAP 0603 CHIP 22P 50V NPO +-1%

C509 018-14100-00 CAP 0603 CHIP 1N 50V X7R +-10%

C514 018-12220-10 CAP 0603 CHIP 22P 50V NPO +-1%

C515 018-12220-10 CAP 0603 CHIP 22P 50V NPO +-1%

C517 015-23680-08 CAP CER 0805 CHIP 680P 10% X7R 50V

C518 015-06100-08 CAP CER 1206 CHIP 100N 10% X7R 50V

C519 015-06100-08 CAP CER 1206 CHIP 100N 10% X7R 50V

C520 015-25220-08 CAP CER 0805 CHIP 22N 10% X7R 50V

C521 015-06100-08 CAP CER 1206 CHIP 100N 10% X7R 50V

C522 018-13150-00 CAP 0603 CHIP 150P 50V NPO +-5%

C524 016-08470-01 CAP ELECT SMD 6X4MM 47M 16V

C525 018-13150-00 CAP 0603 CHIP 150P 50V NPO +-5%

C526 018-13150-00 CAP 0603 CHIP 150P 50V NPO +-5%

C527 018-13150-00 CAP 0603 CHIP 150P 50V NPO +-5%

C528 018-13150-00 CAP 0603 CHIP 150P 50V NPO +-5%

C530 018-13150-00 CAP 0603 CHIP 150P 50V NPO +-5%

C540 018-13150-00 CAP 0603 CHIP 150P 50V NPO +-5%

C541 018-13150-00 CAP 0603 CHIP 150P 50V NPO +-5%

C542 018-13100-10 CAP 0603 CHIP 100P 50V NPO +-1%

C543 018-13100-10 CAP 0603 CHIP 100P 50V NPO +-1%

C544 018-13100-10 CAP 0603 CHIP 100P 50V NPO +-1%

C545 018-13100-10 CAP 0603 CHIP 100P 50V NPO +-1%

C546 015-24330-08 CAP CER 0805 CHIP 3N3 10% X7R 50V

C600 015-25150-08 CAP CER 0805 CHIP 15N 10% X7R 50V

C601 014-07470-01 CAP TANT CHIP 4U7 'B' CASE 25V +-10% 267

C602 018-12820-10 CAP 0603 CHIP 82P 50V NPO +-1%

C603 015-23220-01 CAP CER 0805 CHIP 220P 5% NPO 50V

C604 014-07470-01 CAP TANT CHIP 4U7 'B' CASE 25V +-10% 267

C605 014-07470-01 CAP TANT CHIP 4U7 'B' CASE 25V +-10% 267

C606 015-06100-08 CAP CER 1206 CHIP 100N 10% X7R 50V

C607 015-06100-08 CAP CER 1206 CHIP 100N 10% X7R 50V

C608 018-15100-00 CAP 0603 CHIP 10N 50V X7R +-10%

C609 018-12470-10 CAP 0603 CHIP 47P 50V NPO +-1%

C610 014-07470-01 CAP TANT CHIP 4U7 'B' CASE 25V +-10% 267

C611 018-13100-10 CAP 0603 CHIP 100P 50V NPO +-1%

C612 014-07470-01 CAP TANT CHIP 4U7 'B' CASE 25V +-10% 267

C613 015-24470-08 CAP CER 0805 CHIP 4N7 10% X7R 50V

C614 015-25150-08 CAP CER 0805 CHIP 15N 10% X7R 50V

C615 015-25150-08 CAP CER 0805 CHIP 15N 10% X7R 50V

C616 015-25150-08 CAP CER 0805 CHIP 15N 10% X7R 50V

C617 018-15100-00 CAP 0603 CHIP 10N 50V X7R +-10%

C618 018-15100-00 CAP 0603 CHIP 10N 50V X7R +-10%

C619 018-15100-00 CAP 0603 CHIP 10N 50V X7R +-10%

C620 018-15100-00 CAP 0603 CHIP 10N 50V X7R +-10%

C621 018-15100-00 CAP 0603 CHIP 10N 50V X7R +-10%

C622 018-15100-00 CAP 0603 CHIP 10N 50V X7R +-10%

C623 015-06100-08 CAP CER 1206 CHIP 100N 10% X7R 50V

C624 018-15100-00 CAP 0603 CHIP 10N 50V X7R +-10%

C625 018-15100-00 CAP 0603 CHIP 10N 50V X7R +-10%

C626 014-07470-01 CAP TANT CHIP 4U7 'B' CASE 25V +-10% 267

C627 015-06100-08 CAP CER 1206 CHIP 100N 10% X7R 50V

C628 018-15100-00 CAP 0603 CHIP 10N 50V X7R +-10%

C629 015-23220-01 CAP CER 0805 CHIP 220P 5% NPO 50V

C630 015-25150-08 CAP CER 0805 CHIP 15N 10% X7R 50V

C632 014-07470-01 CAP TANT CHIP 4U7 'B' CASE 25V +-10% 267

C633 016-08470-01 CAP ELECT SMD 6X4MM 47M 16V

C634 015-24470-08 CAP CER 0805 CHIP 4N7 10% X7R 50V

C635 015-06100-08 CAP CER 1206 CHIP 100N 10% X7R 50V

C636 015-06100-08 CAP CER 1206 CHIP 100N 10% X7R 50V

C637 018-11470-10 CAP 0603 CHIP 4P7 50V NPO +-0.1P

C638 015-06100-08 CAP CER 1206 CHIP 100N 10% X7R 50V

C639 016-08470-01 CAP ELECT SMD 6X4MM 47M 16V

C640 016-08470-01 CAP ELECT SMD 6X4MM 47M 16V

C641 018-14100-00 CAP 0603 CHIP 1N 50V X7R +-10%

C642 015-23220-01 CAP CER 0805 CHIP 220P 5% NPO 50V

C643 015-25150-08 CAP CER 0805 CHIP 15N 10% X7R 50V

C644 015-25150-08 CAP CER 0805 CHIP 15N 10% X7R 50V

C645 018-13150-00 CAP 0603 CHIP 150P 50V NPO +-5%

C646 014-07470-01 CAP TANT CHIP 4U7 'B' CASE 25V +-10% 267

C647 015-06100-08 CAP CER 1206 CHIP 100N 10% X7R 50V

C648 016-08470-01 CAP ELECT SMD 6X4MM 47M 16V

C650 018-13150-00 CAP 0603 CHIP 150P 50V NPO +-5%

C651 018-13150-00 CAP 0603 CHIP 150P 50V NPO +-5%

#C700 015-06100-08 CAP CER 1206 CHIP 100N 10% X7R 50V

C702 015-06100-08 CAP CER 1206 CHIP 100N 10% X7R 50V

#C703 015-06100-08 CAP CER 1206 CHIP 100N 10% X7R 50V

C705 015-06100-08 CAP CER 1206 CHIP 100N 10% X7R 50V

#C730 014-07470-01 CAP TANT CHIP 4U7 'B' CASE 25V +-10% 26

D500 001-10000-70 (S) DIODE SMD BAV70 DUAL SWITCH SOT-23 C

IC501 002-10936-60 (LS) IC SMD ST93C66CM6 4K EEPROM SER MI

IC504 002-10340-64 (S) IC SMD MC34064 LO VOLT SENSE

IC505 002-26870-59 (S) IC MC68HC705C9ACFN 8BIT OTP MCU 44

IC506 002-10140-21 (S) IC MC14021BDR2 8BIT SHIFT REGSTR.SO

IC507 002-10140-21 (S) IC MC14021BDR2 8BIT SHIFT REGSTR.SO

IC509 002-74905-95 (S) IC SMD 74HC595 SHIFT REGISTER

#IC510 002-74901-32 (S) IC SMD 74HC132 HCMOS QUAD SCHMT SO

IC511 002-74901-32 (S) IC SMD 74HC132 HCMOS QUAD SCHMT SO-

IC513 002-10078-08 (S) IC SMD 78L08 8V REG SO8

IC601 002-10003-24 (S) IC SMD 324 QUAD OP AMP SO14

IC602 002-10003-24 (S) IC SMD 324 QUAD OP AMP SO14

IC603 002-10003-24 (S) IC SMD 324 QUAD OP AMP SO14

IC604 002-10003-58 (S) IC SMD LM358 DUAL OP AMP

IC614 002-10040-53 (S) IC 4053 SMD TRIPLE 2CH MULTI-PLEXR

L501 056-10330-02 (L) IND SMD 330NH SIEMENS SMID02

P1 240-10000-01 CONN SMD 24WAY (PLUG)

P2 240-10000-01 CONN SMD 24WAY (PLUG)

Q501 000-10084-81 (S) XSTR SMD BC848BW NPN SOT-323 SMALL S

Q502 000-10084-81 (S) XSTR SMD BC848BW NPN SOT-323 SMALL S

Q503 000-10008-69 (S) XSTR SMD BC869 PNP 1W 2A SOT-89

Q504 000-10084-81 (S) XSTR SMD BC848BW NPN SOT-323 SMALL S

Q505 000-10085-71 (S) XSTR SMD BC857BW PNP SOT-323 SMALL S

Q506 000-10085-71 (S) XSTR SMD BC857BW PNP SOT-323 SMALL S

Q507 000-10003-12 (S) XSTR SMD BFR31 N JFET SOT-23

Q508 000-10085-71 (S) XSTR SMD BC857BW PNP SOT-323 SMALL S

Q509 000-10085-71 (S) XSTR SMD BC857BW PNP SOT-323 SMALL S

Q510 000-10084-81 (S) XSTR SMD BC848BW NPN SOT-323 SMALL S

Q520 000-10084-81 (S) XSTR SMD BC848BW NPN SOT-323 SMALL S

Q601 000-10084-81 (S) XSTR SMD BC848BW NPN SOT-323 SMALL S

Q602 000-10084-81 (S) XSTR SMD BC848BW NPN SOT-323 SMALL S

Q603 000-10084-81 (S) XSTR SMD BC848BW NPN SOT-323 SMALL S

Q604 000-10084-81 (S) XSTR SMD BC848BW NPN SOT-323 SMALL S

Q605 000-10085-71 (S) XSTR SMD BC857BW PNP SOT-323 SMALL S

Q606 000-10084-81 (S) XSTR SMD BC848BW NPN SOT-323 SMALL S

Q607 000-10084-81 (S) XSTR SMD BC848BW NPN SOT-323 SMALL S

Q608 000-10084-81 (S) XSTR SMD BC848BW NPN SOT-323 SMALL S

7.10 T2010 & T2015 HC05 Logic PCB

T2010 & T2015 HC05 Logic Parts List (IPN 220-01377-03)

Parts List Amendments
