M2000-00 T2020, T203X, T2040, T2050 & T2060 HC11 Logic PCB 7.11.13
Copyright TEL 31/12/97
Ref Var IPN Description Ref Var IPN Description
IPN 220-01344-04
#012 2050 038-13680-00 RES 0603 CHIP 680E 1/16W +-5%
#015 2020 038-14470-00 RES 0603 CHIP 4K7 1/16W +-5%
#017 2060 038-15100-00 RES 0603 CHIP 10K 1/16W +-5%
#018 203X 038-15270-00 RES 0603 CHIP 27K 1/16W +-5%
#019 2040 038-15470-00 RES 0603 CHIP 47K 1/16W +-5%
C501 015-23680-08 CAP CER 0805 CHIP 680P 10% X7R 50V
C502 018-16100-01 CAP 0603 CHIP 100N +80-20% Y5V 16V
C503 018-16100-01 CAP 0603 CHIP 100N +80-20% Y5V 16V
C504 018-16100-01 CAP 0603 CHIP 100N +80-20% Y5V 16V
C505 018-12390-10 CAP 0603 CHIP 39P 50V NPO +-1%
C506 018-12220-10 CAP 0603 CHIP 22P 50V NPO +-1%
C507 018-12270-10 CAP 0603 CHIP 27P 50V NPO +-1%
C508 018-16100-01 CAP 0603 CHIP 100N +80-20% Y5V 16V
C509 018-14100-00 CAP 0603 CHIP 1N 50V X7R +-10%
C510 018-15100-00 CAP 0603 CHIP 10N 50V X7R +-10%
C511 018-15100-00 CAP 0603 CHIP 10N 50V X7R +-10%
C512 018-14100-00 CAP 0603 CHIP 1N 50V X7R +-10%
C514 018-16100-01 CAP 0603 CHIP 100N +80-20% Y5V 16V
C514A 018-14100-00 CAP 0603 CHIP 1N 50V X7R +-10%
C514B 018-14100-00 CAP 0603 CHIP 1N 50V X7R +-10%
C516 018-16100-01 CAP 0603 CHIP 100N +80-20% Y5V 16V
C517 015-23680-08 CAP CER 0805 CHIP 680P 10% X7R 50V
C519 018-16100-01 CAP 0603 CHIP 100N +80-20% Y5V 16V
C520 018-16100-01 CAP 0603 CHIP 100N +80-20% Y5V 16V
C522 018-16100-01 CAP 0603 CHIP 100N +80-20% Y5V 16V
C523 018-16100-01 CAP 0603 CHIP 100N +80-20% Y5V 16V
C524 016-08470-01 CAP ELECT SMD 6X4MM 47M 16V
C525 018-13150-00 CAP 0603 CHIP 150P 50V NPO +-5%
C526 018-13150-00 CAP 0603 CHIP 150P 50V NPO +-5%
C527 018-13150-00 CAP 0603 CHIP 150P 50V NPO +-5%
C529 018-13150-00 CAP 0603 CHIP 150P 50V NPO +-5%
C530 018-13150-00 CAP 0603 CHIP 150P 50V NPO +-5%
C532 018-14100-00 CAP 0603 CHIP 1N 50V X7R +-10%
C533 018-16100-01 CAP 0603 CHIP 100N +80-20% Y5V 16V
C534 018-16100-01 CAP 0603 CHIP 100N +80-20% Y5V 16V
C535 018-16100-01 CAP 0603 CHIP 100N +80-20% Y5V 16V
C536 014-07470-01 CAP TANT CHIP 4U7 'B' CASE 25V +-10% 26
C537 016-07470-01 CAP ELECT 6X4MM CHIP 4M7 20% 16V
C538 018-16100-01 CAP 0603 CHIP 100N +80-20% Y5V 16V
C540 018-13150-00 CAP 0603 CHIP 150P 50V NPO +-5%
C541 018-13150-00 CAP 0603 CHIP 150P 50V NPO +-5%
C550 018-16100-01 CAP 0603 CHIP 100N +80-20% Y5V 16V
C560 018-16100-01 CAP 0603 CHIP 100N +80-20% Y5V 16V
C570 018-16100-01 CAP 0603 CHIP 100N +80-20% Y5V 16V
C571 018-16100-01 CAP 0603 CHIP 100N +80-20% Y5V 16V
C600 018-14100-00 CAP 0603 CHIP 1N 50V X7R +-10%
C601 014-07470-01 CAP TANT CHIP 4U7 'B' CASE 25V +-10% 26
C602 018-12820-10 CAP 0603 CHIP 82P 50V NPO +-1%
C603 015-23220-01 CAP CER 0805 CHIP 220P 5% NPO 50V
C605 014-07470-01 CAP TANT CHIP 4U7 'B' CASE 25V +-10% 26
C607 015-06100-08 CAP CER 1206 CHIP 100N 10% X7R 50V
C608 018-15100-00 CAP 0603 CHIP 10N 50V X7R +-10%
C609 018-12470-10 CAP 0603 CHIP 47P 50V NPO +-1%
C610 014-07470-01 CAP TANT CHIP 4U7 'B' CASE 25V +-10% 26
C611 018-13100-10 CAP 0603 CHIP 100P 50V NPO +-1%
C613 015-24470-08 CAP CER 0805 CHIP 4N7 10% X7R 50V
C614 015-25150-08 CAP CER 0805 CHIP 15N 10% X7R 50V
C615 015-25150-08 CAP CER 0805 CHIP 15N 10% X7R 50V
C616 015-25150-08 CAP CER 0805 CHIP 15N 10% X7R 50V
C617 018-15100-00 CAP 0603 CHIP 10N 50V X7R +-10%
C618 018-15100-00 CAP 0603 CHIP 10N 50V X7R +-10%
C619 018-15100-00 CAP 0603 CHIP 10N 50V X7R +-10%
C620 018-15100-00 CAP 0603 CHIP 10N 50V X7R +-10%
C621 018-15100-00 CAP 0603 CHIP 10N 50V X7R +-10%
C622 018-15100-00 CAP 0603 CHIP 10N 50V X7R +-10%
C623 015-06100-08 CAP CER 1206 CHIP 100N 10% X7R 50V
C624 018-15100-00 CAP 0603 CHIP 10N 50V X7R +-10%
C625 018-15100-00 CAP 0603 CHIP 10N 50V X7R +-10%
C626 014-07470-01 CAP TANT CHIP 4U7 'B' CASE 25V +-10% 26
C627 015-06100-08 CAP CER 1206 CHIP 100N 10% X7R 50V
C628 018-15100-00 CAP 0603 CHIP 10N 50V X7R +-10%
C629 015-23220-01 CAP CER 0805 CHIP 220P 5% NPO 50V
C630 015-25150-08 CAP CER 0805 CHIP 15N 10% X7R 50V
#C631 2020 015-06100-08 CAP CER 1206 CHIP 100N 10% X7R 50V
#C631 2040 015-06100-08 CAP CER 1206 CHIP 100N 10% X7R 50V
#C631 2050 015-06100-08 CAP CER 1206 CHIP 100N 10% X7R 50V
C635 016-08470-01 CAP ELECT SMD 6X4MM 47M 16V
C635A 016-08470-01 CAP ELECT SMD 6X4MM 47M 16V
C636 015-06100-08 CAP CER 1206 CHIP 100N 10% X7R 50V
C637 018-11470-10 CAP 0603 CHIP 4P7 50V NPO +-0.1P
C638 018-16100-01 CAP 0603 CHIP 100N +80-20% Y5V 16V
C639 016-08470-01 CAP ELECT SMD 6X4MM 47M 16V
C640 016-08470-01 CAP ELECT SMD 6X4MM 47M 16V
C641 018-14100-00 CAP 0603 CHIP 1N 50V X7R +-10%
C642 015-23220-01 CAP CER 0805 CHIP 220P 5% NPO 50V
C643 015-25150-08 CAP CER 0805 CHIP 15N 10% X7R 50V
C644 015-25150-08 CAP CER 0805 CHIP 15N 10% X7R 50V
C645 018-13150-00 CAP 0603 CHIP 150P 50V NPO +-5%
C646 014-07470-01 CAP TANT CHIP 4U7 'B' CASE 25V +-10% 26
C647 018-16100-01 CAP 0603 CHIP 100N +80-20% Y5V 16V
C648 016-08470-01 CAP ELECT SMD 6X4MM 47M 16V
C650 018-13150-00 CAP 0603 CHIP 150P 50V NPO +-5%
C651 018-13150-00 CAP 0603 CHIP 150P 50V NPO +-5%
C652 018-14100-00 CAP 0603 CHIP 1N 50V X7R +-10%
C653 018-14100-00 CAP 0603 CHIP 1N 50V X7R +-10%
#C661 2020 018-16100-01 CAP 0603 CHIP 100N +80-20% Y5V 16V
#C661 203X 018-16100-01 CAP 0603 CHIP 100N +80-20% Y5V 16V
#C661 2040 018-16100-01 CAP 0603 CHIP 100N +80-20% Y5V 16V
#C661 2050 018-16100-01 CAP 0603 CHIP 100N +80-20% Y5V 16V
#C661 2060 018-16100-01 CAP 0603 CHIP 100N +80-20% Y5V 16V
#C662 2020 018-16100-01 CAP 0603 CHIP 100N +80-20% Y5V 16V
#C662 203X 018-16100-01 CAP 0603 CHIP 100N +80-20% Y5V 16V
#C662 2040 018-16100-01 CAP 0603 CHIP 100N +80-20% Y5V 16V
#C662 2050 018-16100-01 CAP 0603 CHIP 100N +80-20% Y5V 16V
#C662 2060 018-16100-01 CAP 0603 CHIP 100N +80-20% Y5V 16V
#C663 2020 018-16100-01 CAP 0603 CHIP 100N +80-20% Y5V 16V
#C663 203X 018-16100-01 CAP 0603 CHIP 100N +80-20% Y5V 16V
#C663 2040 018-16100-01 CAP 0603 CHIP 100N +80-20% Y5V 16V
#C663 2050 018-16100-01 CAP 0603 CHIP 100N +80-20% Y5V 16V
#C663 2060 018-16100-01 CAP 0603 CHIP 100N +80-20% Y5V 16V
#C664 2020 018-16100-01 CAP 0603 CHIP 100N +80-20% Y5V 16V
#C664 2040 018-16100-01 CAP 0603 CHIP 100N +80-20% Y5V 16V
#C664 2050 018-16100-01 CAP 0603 CHIP 100N +80-20% Y5V 16V
#C664 2060 018-16100-01 CAP 0603 CHIP 100N +80-20% Y5V 16V
#C665 2020 018-16100-01 CAP 0603 CHIP 100N +80-20% Y5V 16V
#C665 2040 018-16100-01 CAP 0603 CHIP 100N +80-20% Y5V 16V
#C665 2050 018-16100-01 CAP 0603 CHIP 100N +80-20% Y5V 16V
#C665 2060 018-16100-01 CAP 0603 CHIP 100N +80-20% Y5V 16V
#C666 2020 018-16100-01 CAP 0603 CHIP 100N +80-20% Y5V 16V
#C666 2040 018-16100-01 CAP 0603 CHIP 100N +80-20% Y5V 16V
#C666 2050 018-16100-01 CAP 0603 CHIP 100N +80-20% Y5V 16V
#C666 2060 018-16100-01 CAP 0603 CHIP 100N +80-20% Y5V 16V
#C667 2020 018-16100-01 CAP 0603 CHIP 100N +80-20% Y5V 16V
#C667 2040 018-16100-01 CAP 0603 CHIP 100N +80-20% Y5V 16V
#C667 2050 018-16100-01 CAP 0603 CHIP 100N +80-20% Y5V 16V
#C667 2060 018-16100-01 CAP 0603 CHIP 100N +80-20% Y5V 16V
C700 014-07470-01 CAP TANT CHIP 4U7 'B' CASE 25V +-10% 26
C701 016-08470-01 CAP ELECT SMD 6X4MM 47M 16V
#C704 2020 014-07470-01 CAP TANT CHIP 4U7 'B' CASE 25V +-1
#C704 203X 014-07470-00 CAP TANT CHIP 4U7 'B' CASE 16V +-1
#C704 2040 014-07470-01 CAP TANT CHIP 4U7 'B' CASE 25V +-1
#C704 2050 014-07470-01 CAP TANT CHIP 4U7 'B' CASE 25V +-1
#C704 2060 014-07470-01 CAP TANT CHIP 4U7 'B' CASE 25V +-1
C705 015-24470-08 CAP CER 0805 CHIP 4N7 10% X7R 50V
#C706 203X 015-06100-08 CAP CER 1206 CHIP 100N 10% X7R 50V
#C706 2060 015-06100-08 CAP CER 1206 CHIP 100N 10% X7R 50V
C720 018-16100-01 CAP 0603 CHIP 100N +80-20% Y5V 16V
7.11 T2020, T203X, T2040, T2050 & T2060 HC11 Logic PCB
T2000 HC11 Logic Parts List (IPN 220-01344-04)
Parts List Amendments
