IPN 220-01396-02
B6.3.10
T855 PCB Information
M850-00
31/09/98 Copyright TEL
IPN Legend Description IPN Legend Description
T855 Mechanical & Miscellaneous Parts (220-01396-02)
066-00010-20 1 SLUG BRASS A4M764 HELIC RESNTR
070-01001-00 15/28 D-RANGE 15 WAY COMPL T800
070-02001-00 LED RED COMPL T800 RX/TX/EX
070-02002-00 LED GREEN COMPL T800 RX/TX/EX
200-00010-04 WIRE T/C 0.7
220-01145-02 2 PCB T855/856/857 VCO
220-01396-02 3 PCB T855 SERIES II
230-00010-31 4 SWITCH COVER FOR 230-00010-30
240-02100-06 5 SKT COAX N TYPE PNL MTG OP-TER
240-04020-62 SKT 2 W RECEP SHORTING LINK
PL210/220/230/240/250/260/270
303-11169-03 6 CHASSIS PAINTED T800 SERIES
303-23118-00 7 COVER A3M2247 D RANGE T855/7
303-50074-00 8 CLIP A3M2246 SPRING CLAMP T857
308-01007-01 9 HANDLE BASE STATION SERIES II
308-01048-00 10 HOUSING A3M2378 DOUBLET H/RES
311-01015-00 11 KNOB 15MM & SKIRT 6MM SFT
312-01052-01 12 LID TOP PNTD A1M2364 T800
312-01053-01 13 LID BOTTOM PNTD A1M2364 T800
316-06622-00 14 PNL FRT RX T800 SERIES II
345-00040-10 16 SCRW M3X6MM P/POZ ST BZ
349-00020-36 17 LIM)SCREW TT M3X8m PANTORX BLK
349-00020-43 18 SCRW T/T M4X12MM P/POZ BZ
349-00020-45 19 SCRW T/T M4X20MM P/POZ BZ
350-00016-42 20 SPACER 5MM HI 8MM ST 2.5MM HO
352-00010-08 21 NUT M3 COLD FORM HEX ST BZ
352-00010-29 22 NUT M4 NYLOC HEX
352-00010-54 23 NUT BRASS HEX 1/4" UNF 3MM
353-00010-10 24 WSHR M3 FLAT 7MMX0.6MM ST BZ
353-00010-13 25 WSHR M3 S/PROOF INT BZ
356-00010-03 TAG SOLDER 3MM LONG M614/3.2
Main PCB to chassis earth strap (via D-range
shield).
362-00010-23 26 GASKET SIL TO-220 CLIP MTG.
362-00010-33 27 GROMMET LED MTG 3MM
365-00011-53 LABEL 104X37MM
365-00100-20 LABEL WHITE S/A 28X11MM
365-01541-00 LABEL TX/RX/EX TYPE APR/SER NO
399-00010-51 BAG PLASTIC 75X100MM
410-01081-01 CRT T800 SERIES II
410-01082-01 CRTN 10 T800 KIWI 423X410X360
