24 |
7 & 12 PIN PLUG (CARAVANS)
Talvor caravans are equipped with a 7 pin
at plug and it is wired according to the
following code:
Circuit
Conductor
Circuit
conductor
colour
1 Left-hand turn Yellow
2 Reversing signal Black
3 Earth return White
4 Right-hand turn Green
5 Service brakes Blue
6 Stop lamps Red
7 Rear lamps,
clearance & side
marker lamps
Brown
ANDERSON PLUG (CARAVANS)
Talvor caravans are equipped with a 50 amp
Anderson plug which allows the tow vehicle
to charge the ancillary batteries in your van.
Note the vehicle battery will charge rst
and when fully charged the alternator will
charge the ancillary battery or batteries.
