Tanaka TED-262L Illustrated Parts Manual

www.tanakapowerequipment.com
PARTS INFORMATION
custsvc@nikko-tanaka-usa.com
Page 6
TED-262L/DH
FUEL SYSTEM • FIGURE 4
ITEM PART NUMBER DESCRIPTION QTY COMMENTS
4-5 65301620200 BRACKET,TANK 1
4-7 65506100200 CUSHION,TANK 4
4-33-1 40301620201 GASKET,INLET MANIFOLD 1 ~S279070
4-33 4030160020 GASKET,INLET MANIFOLD 1 S279071~
4-34-1 4040162022 INSULATOR,CARBURETOR 1 ~S279070
4-34 4040160091 INSULATOR SET 1 S279071~ Includes gasket
4-35-1 4020060120 GASKET,CARBURETOR 1 ~S279070
4-35 4020602K21 GASKET,CARBURETOR 1 S279071~
4-36 4550160090 CARBURETOR SET 1 S279071~ Includes gasket
4-36-1 45525023900 CARBURETOR ASSY 1 ~S279070
4-37 2230162V900 PIPE,FUEL,ASS'Y 1 ~S279070
4-37 2230650090 PIPE,FUEL,ASS'Y 1 S279071~
4-40 6750608A900 FILTER,FUEL 1
4-41 68000731201 CLIP 6.3 1
4-42 5950650A90 CAP,TANK 1 ~T253552
4-42 5950656B90 CAP,FUEL BLACK,NON VENT 1 T253553~
4-53 5910162T220 TANK,FUEL 1 ~T253552
4-53 5910160020 TANK,FUEL 1 T253553~
4-57 99415040182 SCREW,PS,4X18 2
4-74 99416050601 SCREW,5x60WS 2 ~R007764
4-74 99416050651 SCREW,5X65/WS 2 ~S279070
4-74 99416050601 SCREW,5x60WS 2 S279071~
4-76 99178050010 NUT,LOCK 5 2 ~S279070
4-81 99415040142 SCREW,4X14/PS 2
4-86 99416050221 SCREW,5X22/WS 2 ~S279070
4-86 99416050241 SCREW 5x24WS 2 S279071~
4-121 5640661190 VENT,AIR ASS'Y 1 T253553~
4-122 5650441020 PIPE,AIR VENT 1 T253553~
4-123 6460661290 VALVE 1 T253553~
4-124 68000206200 CLIP,5.5 1 T253553~
4-124 68000206200 CLIP,5.5 1 ~V168600
4-125 5610007020 COVER,AIR VENT 1 T253553~
4-125 5610007020 COVER,AIR VENT 1 ~V168600
