CVS 8
CVS 8 // issue 1.03 // 02.03.11
Tannoy adopts a policy of continuous improvement and product specication is subject to change
Tannoy (Direct UK) T: 00 44 (0) 1236 420199 E: enquiries@tannoy.com
TCGI (ROW sales) T: 00 45 8742 7000 E: info@tcgroup-international.com
TCGA (Americas sales) T: 00 1 (519) 745 1158 E: info@tcgroup-americas.com
Tannoy Middle East T: 00 971 (04) 4401208 E: enquiries@tannoy.com
TECHNICAL SPECIFICATIONS
System CVS 8
Frequency Response (-3dB)
(1)
79Hz - 21kHz
Frequency Range (-10dB)
(1)
60Hz - 24kHz
System Sensitivity (1W @1m)
(2)
93dB (1W = 2.45V for 6 Ohms)
Nominal Coverage Angle 90 degrees conical
Coverage Angle (1kHz to 6kHz) 84 degrees conical
Directivity Factor (Q) 14.7 averaged 1kHz to 6kHz
Directivity Index (DI) 11.7 averaged 1kHz to 6kHz
Rated Maximum SPL
(2)
111dB (average)
117dB (peak)
Power Handling
(3)
Average 60W
Programme 120W
Peak 240W
Recommended Amplier Power 120W @ 6 Ohms
Nominal Impedance 6 Ohms
Transformer Taps
(via front rotary switch)
70V 60W / 30W / 15W / 7.5W / OFF
& low impedance operation
100V 60W / 30W / 15W / OFF
& low impedance operation
Distortion
1% Full Power 2nd Harmonic 3rd Harmonic
250Hz 0.33% 0.25%
1kHz 0.15% 0.63%
10kHz 0.12% 0.03%
10% Full Power 2nd Harmonic 3rd Harmonic
250Hz 1.10% 0.25%
1kHz 0.55% 0.70%
10kHz 0.52% 0.03%
Crossover Point 6kHz
Notes
(1) 1. Average over stated Bandwidth. Measured in an IEC bafe in an Anechoic
Chamber
(2) Unweighted Pink noise input, measured at 1m on axis
(3) Long term power handling capacity as dened in EIA - 426B test
A full range of measurements, performance data, CLF and Ease™ Data can be
downloaded from www.tannoy.com
Full independent verication of published specications carried out by NWAA Labs,
Washington can also be obtained from the downloads section of www.tannoy.com
Tannoy operates a policy of continuous research and development. The introduction
of new materials or manufacturing methods will always equal or exceed the
published specications, which Tannoy reserves the right to alter without prior
notice. Please verify the latest specications when dealing with critical applications.
Ordering Information
PART NUMBER MODEL NAME COLOUR PACKED QUANTITY
8001 6290 CVS 8 WHITE / PAINTABLE 2
Transducers
Low Frequency Coaxial
200mm (8.00”) mineral
loaded cone material
High Frequency 19mm (0.75”)
Physical
Enclosure Blind Mount (BM)
Back can Painted steel
Bafe Reex loaded UL 94V-0 rated ABS
Grille Steel, with weather resistant coating
Safety Features Safety ring located at rear of
enclosure for load bearing
safety bond
Clamping Design Security toggle clamp
Back Can
Cable Entry Options Cable clamp & squeeze connector
for conduit up to 22mm
Connectors Removable locking connector
with screw terminals with “loop
through” facility
Safety Agency Ratings (pending) UL-1480, UL-2043, CE
Hole Cutout Diameter 320mm (12.6”)
Dimensions
Bezel diameter 355.6mm (14.00”)
Front of ceiling to
rear of back can 251.0mm (9.88”)
Front of ceiling to
top of safety loop 264.0mm (10.39”)
Template hole cutout size 250mm (9.84”)
Net Weight (ea) 5.3kg (11.68lbs)
Included Accessories C-ring,Tile bridge, paint mask,
cutout template, grille
Optional Accessories Plaster (mud) ring
.
6483 1140 / 0311
