Tannoy Di5a - Speaker Component Identification

4
YOKE TRIM
Remove the yoke trims on the top
and bottom panels to access the
yoke bracket fixing point
GRILLE TRIM
Lift the grille trim back using the
tab to access the level control.
GRILLE
LINE LEVEL AUDIO
INPUT SOCKET
(RCA TYPE)
LINE LEVEL AUDIO
INPUT/ OUTPUT
SOCKET (EURO TYPE)
POWER INPUT
SOCKET (IEC TYPE)
POWER ON/ OFF SWITCH
