4
YOKE TRIM
Remove the yoke trims on the top
and bottom panels to access the
yoke bracket fixing point
GRILLE TRIM
Lift the grille trim back using the
tab to access the transformer
tapping switch on transformer
models.
INPUT CONNECTOR
Remove the rubber grommet to
access the connector. The
rubber grommet ensures the rear
of the product is kept water-tight
SAFETY TAB
GRILLE
