Tannoy GOLD Series User Manual

Other important information
1. Register online.
Pleaseregister your new MUSIC Group
equipment right after you purchase it
purchase using our simple online
form helps us to process your repair
claims more quickly and e ciently.
Also, read the terms and conditions of
our warranty, ifapplicable.
2. Malfunction. Should your
MUSICGroup Authorized Reseller not be
located in your vicinity, you may contact
the MUSIC Group Authorized Ful ller for
your country listed under “Support” at
listed, pleasecheck if your problem can be
dealt with by our “OnlineSupport” which
may also be found under “Support” at
BEFORE returning theproduct.
3. Power Connections.
Beforeplugging the unit into a power
socket, please make sure you are using the
correct mains voltage for your particular
model. Faulty fuses must be replaced
with fuses of the same type and rating
withoutexception.
Important information Aspectos importantes
Informations importantes
GOLD 8 GOLD 7 GOLD 5
System
Frequency response
54 Hz – 20 kHz ±3 dB
40 Hz – 20 kHz -10 dB
65 Hz – 20 kHz ±3 dB
46 Hz – 20 kHz -10 dB
70 Hz – 20 kHz ±3 dB
49 Hz – 20 kHz -10 dB
Nominal dispersion 90° conical @ -6 dB point
Maximum SPL 110 dB 107 dB
Crossover type 2 way, active
Crossover frequency 1.5 kHz 2 kHz
Transducers
1 x 8" (203 mm) LF driver
1 x 1" (25.4 mm) HF drivers
1 x 6.5" (165 mm) LF driver
1 x 1" (25.4 mm) HF drivers
1 x 5" (127 mm) LF driver
1 x 0.8" (20 mm) HF drivers
Limiter Independent high and low frequency limiters
Magnetic shielding No
Ampli er
Maximum output power 300 W 200 W
Type Class-AB
Protection Short circuit, thermal
Connectors
Inputs
1 x XLR, balanced
1 x ¼ " TRS, balanced
3.5 mm stereo mini jack
Sensitivity 0 dBu, nominal
Input impedance 5 k unbalanced, 10 k balanced
Maximum input level +20 dBu
Outputs Monitor link, 3.5 mm stereo mini jack
User controls Power on / o , Input trim, HF trim, Bass adjustment, Auto-standby on / o
Power Supply
Power consumption 80 W @ ⁄ max power 70 W @ ⁄ max power 50 W @ ⁄ max power
Voltage (fuses) 100-240 V~, 50/60 Hz (T 3.15 A L 250 V)
Mains supply IEC mains connector with integrated power switch
Enclosure
Dimensions (HWD)
429x 274 x 336 mm
(16.9 x 10.8 x 13.2")
357x 221 x 288 mm
(14.0 x 8.7 x 11.3")
294x 183 x 252 mm
(11.6 x 7.2 x 9.9")
Net weight 14.0 kg (30.8 lbs) 9.4 kg (20.7 lbs) 5.8 kg (12.8 lbs)
Speci cations
12 13Quick Start GuideGOLD SERIES
