TUNet® TC-1220 Quick Reference
KT-24534 Proprietary and Confidential Page 2
TUNet® LAN Module Network Status LED (Red)
Start-up/Power-up Solid ON (Fast flashing indicates module is not programmed)
Unassociated/Re-associating Solid ON
Valid association candidate found Flashing
Full network association confirmed OFF
TUNet® LAN Module Message Status LED (Green)
Start-up/Power-up OFF
Message queued for transmission Long flash
Valid message received (addressed to this device) Short flash
TUNet® LAN Module Transceiver (XVR) LED (Amber)
Start-up/Power-up OFF
RF packet transmitted Long flash
RF packet received (LAN activity) Short flash
Specifications
Frequency Range: 902-928 MHz frequency hopping,
license exempt
Operating Temperature: -22 to 140°F (-30 to +60°C)
Modulation: FSK Operating Humidity: 5 to 95% non-condensing
Antenna: under the glass Standards:
Power supply: 120V/240VAC FCC CFR Title 47 Part 15b (unintentional radiators)
Power consumption: Quiescent 0.75 watts typical
ANSI C12.1:2001 Sections:
4.7.3.1 Insulation, 4.7.3.11 EFT/Burst
4.7.3.3.1 Surge Immunity, 4.7.3.3.2 Ring Wave Immunity
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This
device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation. Changes or modifications to this device not expressly approved by
Tantalus Systems Corp. could void the user's authority to operate the equipment.
Tantalus, TUNet, Tantalus Utility Network, the stylized T logo, and the names of the products and services offered therewith, are trademarks
of Tantalus Systems Corp. All other product and brand names referenced herein may be trademarks of their respective owners.
Tantalus assumes no responsibility for errors or omissions in this document or their consequences. The information is subject to change without
notice. Please report any errors to Tantalus at the address above.
Contact Tantalus
Address all comments to:
Technical Support
Tantalus Systems Corp.
301 – 3480 Gilmore Way
Burnaby, B.C. V5G 4Y1
Telephone: 604-299-0458
Fax: 604-451-4111
Web http://www.tantalus.com
Email: techsupport@tantalus.com
Copyright © 2012 Tantalus Systems Corp. All rights
reserved. No part of this document or associated
software may be reproduced, adapted, stored or
transmitted in any form or by any means except with prior
permission of Tantalus Systems Corp. or as explicitly
allowed by copyright laws applicable to your situation.
This document contains proprietary information of
Tantalus Systems Corp. that may be
disclosed only to
your permitted workers and users of TUNet ® products
and services who need to know.
