Tapworks AD11 User And Installer Handbook

3
Identifying major parts of your water softener
Please Remember – Only use tablet or pellet salt in your softener!
Control Valve Cover
and Electronic Faceplate
Salt Lid
Water Softener Valve
and Motor
Rim
Brine Well and Cover
Overflow Connection
Salt Cabinet
1
3
6
7
5
2
4
Description Quantity
Easy Install Tees 1pair G1038
By pass set (3 valves) 1set B505 (1)
B534 (2)
15mm reducer 2 39845
Inlet/Outlet Hoses 2 803189
Hose Gaskets 4 803188
Adaptor Elbows 2 7255583
Adaptor Clips 1pair 7109041
Silicone Grease 1 n/a
Drain & Overflow Tubing 1 10069
Overflow Elbow 1 7109041
Overflow Grommet 1 7109041
Drain & Overflow hose clips 2 7109041
Transformer 1 7323679
Hard Water Test Kit 1 800005
Spares-Adaptor ‘O’ Rings 2 7109041
(with prefitted adaptor ‘O’ rings)
(incorporates check valve)
(if required)
Note
Model number and serial number are required for
registration of warranty (located under salt lid).
